Experiment V progress & DWC anthroponics

Recently I started the V anthroponics experiment at Hemmaodlat with the goal of testing if Iron is the limiting nutrient in an anthroponics system. I set up the usual three systems. Each received 165mL of aged urine and each received 37g of wood ash (as detailed in experiment IV). However, System 2 received an additional 1g of chelated iron and System 3 received 2g of chelated iron. System 1 received no iron and would serve as control.

The iron selected was the one available at Hemmaodlat: FeDPTA 10% (powder form). Considering that the anthroponic systems have around 30-35L of water volume, and a target iron concentration for healthy cucumber growth is of 3mg/L in the water, the calculations were simple:

1g of powder contains 0,1g Fe. To achieve the concentration of 3mg/L in 35L one would need to add 105mg of powder. Since the powder has a concentration of iron of 10%, then we need 1050mg or 1,05g of powder. System 3 would then receive double the amount to test for any extra benefits to a doubling of iron supplementation.

The experiment was set up on the 27/7/2016, but only one week afterwards (yesterday) I noticed the plants had been attacked by thrips. Below you can see some pictures of the set-up and plant damage.

IMG_20160803_180143 IMG_20160803_180147 IMG_20160803_180152 IMG_20160803_180203

You can see the actual thrips and their inflicted damage on this close-up picture.


So the experiment had to be stopped as the thrip infestation would affect the results. We are sterilizing the media and we will have to re-seed cucumber and wait for the seedlings to have a decent size before restarting the experiment.

In the meantime, I have also started a proof of concept of a different anthroponics system. The goal was to separate the growing component from the ageing & filtration components. The first component is a bucket inside a larger box with a lid. The bucket is filled with water and contains in it a water pump and air-stones. The bucket is also filled with plastic carriers/media (K1). The airstones are then connected to an air pump inside the box, and the water pump has a pipe/tubing to the growing component. The bucket system also contains crushed and dehusked watermelon seeds. As fresh urine is added, the urea will be converted to ammonia, and then the nitrifying bacteria will develop. Once nitrates are measured in the system, it is good to go.


Next to this box is a DWC (Deep Water Culture) hydroponic set-up, also with an airstone connected to an air pump. Given enough time after the urine insertion in the first box, part of the water is then ready to be pumped to the DWC component. I have added some basil seedlings we had available to see how they will react in this system.

IMG_20160803_185035 IMG_20160803_185039

Overall the point will be to test the proof-of-concept and to improve it rather than performing a more scientific trial. But if it works, one can imagine the applications of developing an anthroponic filter that connects to an existing (urine separation) toilet, and its discharge can be used directly as an organic hydroponic solution. This would finally solve the issue of urine handling, which is currently one of the least pleasant activities in anthroponic farming.

New anthroponics trial

Recently a bachelor student of Physical Geography will be doing her thesis in anthroponics and I will be supervising her thesis. For this reason, we will be redoing the trial with wood ash and cucumbers to confirm the initial results we obtained. Since her thesis will be written in swedish, I will write a technical report in english as well. For now, we have just placed the seedlings:


This time, we have brought the pH down to the 5,5 – 6,5 range suited for cucumbers before placing the seedlings, to prevent any shock to the plant. In the last trial (10/01/16 – 29/03/16), before removing the best performing cucumber after 79 days (from system 3, which had 72g of wood ash), I also conducted a general chemical test to the assess the water quality. Here you can see the overall size of the cucumber and some of the deficiencies. Total length was about 140cm, though there were several branches.

IMG_20160322_175015 IMG_20160329_175555 IMG_20160329_181511 IMG_20160330_182932

Based on some observations of interveinal chlorosis in the leaves and 0,00mg/L of Fe in water, it was obvious the plant had an iron deficiency. The concentration of phosphorus was also below the recommended level, though there were no clear signs of deficiency. There seemed to be some potential signs of sulfur deficiency given that upper leaves remained small, curled downwards and with serrated margins, but I do not have the reagents or the resources to test sulfur.

With this new trial, besides our own limited chemical analysis, we hope to get the support of her university to do some more depth tests, such as tissue analysis of the leaves, and water quality by the university laboratory. However, it seems the tests are very expensive and even the university cannot afford to do all the ones that we wanted. A lack of proper laboratory analysis of anthroponics systems seems to be a recurring theme given that there is still very little academic interest in the topic at the moment.

Regardless, our first water quality analysis before adding the seedlings seems to indicate an abundance of all macro and micronutrients with the notable exception of Iron, which had 0,00mg/L in all three systems. Like aquaponics systems, Iron is a common micronutrient that is lacking and must be supplemented. It seems after we have ran this trial that the next focus will be to find a way to supplement Iron in a sustainable way, and possibly any other nutrients we may find lacking.

Anthroponics vision of urban farming

I am currently working with a Swedish NGO to develop a compact and portable anthroponics module that condenses the essential processes and allows an urban farmer to retrieve from it an organic nutrient solution for hydroponic use. The goal will be to achieve external funding to set up a pilot system and test everything to a bigger scale, since we can confirm it works at a worker scale.



Third anthroponic trial

Our third anthroponic experiment is underway and we are already starting to see some differences in the control cucumber! One downside of having added the wood ash (and even without) is that the pH has been quite high (above 7,00 for control and above 10,00 for system 2 and 3). As such, I have added “pH down” (also known as phosphoric acid) in different amounts and gradually over 2-3 weeks to bring the pH levels below 7,00 in all systems. Some of the older leaves in the plants in system 2 and 3 show the initial struggle with the high pH, but now that it’s more stabilized we can see the system where wood ash was not added is struggling with some form of nutrient deficiency.


As usual, expect a full report at the end of this experiment.

Full report: Lactuca sativa production in an anthroponics system

Below follows the full report on Hemmaodlat’s first experiment with anthroponics. Our initial objective of testing different urine dosages was not achieved as the urine added for cycling was enough to grow all the lettuce seedlings until harvest. Thus a new experiment will be conducted with a different crop and different urine dosages.

Direct link to document here.
